On Grid Inverter, Solar Inverter, Solis
Solis 10kW On-Grid Solar Inverter with Wifi Dongle
Availability:
100 in stock
- Solis is a name of trust and soils 10KW on gird inverter is very powerful inverter. It is super-efficient and come with high 98% efficiency rate. We understand the electricity fluctuation in Pakistan, this inverter Works great even better when power is low and adjusts to different power levels easily. It’s got a smart system that grabs the most energy without causing any fuss to your electric grid, keeping things quiet with less than 1.5% disturbance. Additional It has a safety featured that can even protect it against wrong wiring, sudden power jumps, and overheating.
₨ 225,000
100 in stock
CompareSolis is a name of trust and soils 10KW on gird inverter is very powerful inverter. It is super-efficient and come with high 98% efficiency rate. We understand the electricity fluctuation in Pakistan, this inverter Works great even better when power is low and adjusts to different power levels easily. It’s got a smart system that grabs the most energy without causing any fuss to your electric grid, keeping things quiet with less than 1.5% disturbance. Additional It has a safety featured that can even protect it against wrong wiring, sudden power jumps, and overheating.
PRODUCT DETAILS
- Up to 98% Efficiency
- Wide Voltage Range and low start-up Voltage
- 2 MPPT Design with precise MPPT algorithm
- THDi <1.5%, Low harmonic distortion against grid
- Multiple protections levels
Datasheet
| Model Name | Solis-1P10K-4G |
Input DC
| Max. input power | 11.5kW |
| Max. input voltage | 600V |
| Rated voltage | 330V |
| Start-up voltage | 120V |
| MPPT voltage range | 100-500V |
| Max. input current | 10A/10A/10A |
| Max. Short Circuit current | 15.6A/15.6A/15.6A |
| MPPT number/Max. input strings number | 3/3 |
Output AC
| Rated output power | 10kW |
| Max. apparent output power | 10kVA |
| Max. output power | 10kW |
| Rated grid voltage | 1/N/PE, 220V/230V |
| Rated grid frequency | 50Hz/60Hz |
| Rated grid output current | 45.5A/43.5A |
| Max. output current | 45.9A |
| Power Factor | >0.99 (Adjustable from 0.8 leading to 0.8 lagging) |
| THDi | <1.5% |
Efficiency
| Max. efficiency | 98.1% |
| EU efficiency | 97.6% |
Protection
| DC reverse-polarity protection | Yes |
| Short circuit protection | Yes |
| Output over current protection | Yes |
| Surge protection (DC/AC) | Yes |
| Grid monitoring | Yes |
| Islanding protection | Yes |
| Temperature protection | Yes |
| Integrated DC switch | Optional |
General Data
| Dimensions (W*H*D) | 333mm*573mm*249mm |
| Weight | 18kg |
| Topology | Transformerless |
| Self consumption | <1W (Night) |
| Operating ambient temperature range | -25~60°C |
| Relative humidity | 0~100% |
| Ingress protection | IP65 |
| Cooling concept | Natural convection |
| Max. operation altitude | 4000m |
|
Grid connection standard |
VDE-AR-N 4105, VDE V 0124, VDE V 0126-1-1, UTE C15-712-1, NRS 097-1-2, G98, G99, EN 50549-1/-2, RD 1699, UNE 206006, UNE 206007-1, IEC61727 |
| Safety/EMC standard | IEC 62109-1/-2, IEC62116 & EN 61000-6-1/-2/-3/-4 |
Features
| DC connection | MC4 |
| AC connection | IP67 Rated plug |
| Display | LCD, 2×20 Z. |
| Communication | RS485; WiFi/GPRS (optional) |
